SOF45 :
45° face mills, using square or octagonal double-sided inserts with 8/16 cutting edges (HELIDO 845 line).
Designation
D
D1
Z
L
ap
Da
D3
L3
ap3
Arbor
Coolant
Kg
SOF45 8/16-D040-04-22R
40.00
50.4
4
40.00
3.50
22.00
37.65
41.20
6.00
A
Y
0.30
SOF45 8/16-D050-03-22R
50.00
60.4
3
40.00
3.50
22.00
47.65
41.20
6.00
A
Y
0.38
SOF45 8/16-D050-04-22R
50.00
60.4
4
40.00
3.50
22.00
47.65
41.20
6.00
A
Y
0.39
SOF45 8/16-D050-06-22R
50.00
60.4
6
40.00
3.50
22.00
47.65
41.20
6.00
A
Y
0.37
SOF45 D050-04-22-R13
52.35
62.8
4
38.80
3.50
22.00
50.00
40.00
6.00
A
Y
0.38
SOF45 8/16-D063-04-22R
63.00
73.4
4
40.00
3.50
22.00
60.65
41.20
6.00
A
Y
0.57
SOF45 8/16-D063-06-22R
63.00
73.4
6
40.00
3.50
22.00
60.65
41.20
6.00
B
N
0.47
SOF45 8/16-D063-08-22R
63.00
73.4
8
40.00
3.50
22.00
60.65
41.80
6.00
B
N
0.46
SOF45 D063-06-22-R13
65.35
75.8
6
38.80
3.50
22.00
63.00
40.00
6.00
B
Y
0.49
SOF45 D063-06-25.4-R13
65.35
75.8
6
38.80
3.50
25.40
63.00
40.00
6.00
B
Y
1.10
SOF45 8/16-D080-04-25.4R
80.00
90.4
4
50.00
3.50
25.40
77.65
51.20
6.00
B
N
0.00
SOF45 8/16-D080-07-25.40R
80.00
90.4
7
50.00
3.50
25.40
77.65
51.20
6.00
B
N
0.61
SOF45 8/16-D080-07-27R
80.00
90.4
7
50.00
3.50
27.00
77.65
51.20
6.00
B
N
1.01
SOF45 8/16-D080-10-25.40R
80.00
90.4
10
50.00
3.50
25.40
77.65
51.20
6.00
B
N
4.19
SOF45 8/16-D080-10-27R
80.00
90.4
10
50.00
3.50
27.00
77.65
51.20
6.00
B
N
1.23
SOF45 D080-07-25.4-R13
82.35
90.4
7
48.80
3.50
25.40
80.00
50.00
6.00
B
Y
1.52
SOF45 D080-07-27-R13
82.35
90.4
7
48.80
3.50
27.00
80.00
50.00
6.00
B
Y
1.00
SOF45 8/16-D100-05-31.75R
100.00
110.4
5
50.00
3.50
31.75
97.65
51.20
6.00
B
N
0.01
SOF45 8/16-D100-08-31.75R
100.00
110.4
8
50.00
3.50
31.75
97.65
51.20
6.00
B
N
1.41
SOF45 8/16-D100-08-32R
100.00
110.4
8
50.00
3.50
32.00
97.65
51.20
6.00
B
N
1.38
SOF45 8/16-D100-12-31.75R
100.00
110.4
12
50.00
3.50
31.75
97.65
51.20
6.00
B
N
1.63
SOF45 8/16-D100-12-32R
100.00
110.4
12
50.00
3.50
32.00
97.65
51.20
6.00
B
N
1.34
SOF45 D100-08-31.75-R13
102.35
112.8
8
48.80
3.50
31.75
100.00
50.00
6.00
B
N
1.78
SOF45 D100-08-32-R13
102.35
112.8
8
48.80
3.50
32.00
100.00
50.00
6.00
B
Y
1.49
SOF45 8/16-D125-06-38.1R
125.00
135.6
6
63.00
3.50
38.10
122.65
64.20
6.00
B
N
2.94
SOF45 8/16-D125-10-38.10R
125.00
135.6
10
63.00
3.50
38.10
122.65
64.20
6.00
B
N
3.20
SOF45 8/16-D125-10-40R
125.00
135.6
10
63.00
3.50
40.00
122.65
64.20
6.00
B
N
2.63
SOF45 8/16-D125-16-38.10R
125.00
135.6
16
63.00
3.50
38.10
122.65
64.20
6.00
B
N
3.14
SOF45 8/16-D125-16-40R
125.00
135.6
16
63.00
3.50
40.00
122.65
64.20
6.00
B
N
2.55
SOF45 D125-10-40-R13
127.35
137.8
10
61.80
3.50
40.00
125.00
63.00
6.00
B
Y
2.65
SOF45 8/16-D160-12-40R
160.00
170.4
12
63.00
3.50
40.00
157.65
64.20
6.00
B
N
3.34
SOF45 8/16-D200-14-60R
200.00
210.4
14
63.00
3.50
60.00
197.65
64.20
6.00
B
N
5.79
SOF45 8/16-D250-16-60R
250.00
-
16
-
3.50
60.00
44.00
-
6.00
-
-
8.15
SOF45 8/16-D315-20-60R
315.00
-
20
-
3.50
60.00
38.00
-
6.00
-
-
19.07
Use only Torx Plus keys
