TGSF :
TANGSLIT slitting cutters with TANG-GRIP inserts.
Designation
W
D
Z
A
Da
Tmax
RPM
max
a°
D3
A2
SS
CSI
TGSF 50-2-8KR
2.00
50.00
5
1.65
8.00
10.00
1600
90
28.00
2.5
-
-
TGSF 63-2-10KR
2.00
63.00
6
1.65
10.00
14.50
1260
90
32.00
2.5
-
-
TGSF 80-2-22KR
2.00
80.00
8
1.65
22.00
19.00
1000
90
40.00
2.5
-
-
TGSF 100-2-22KR
2.00
100.00
11
1.65
22.00
29.00
800
90
40.00
2.5
-
-
TGSF 125-2-32KR
2.00
125.00
13
1.65
22.00
34.00
640
90
55.00
2.5
-
-
TGSF 50-3-8K
3.00
50.00
4
2.50
8.00
10.00
6300
90
-
-
-
-
TGSF 63-3-10K
3.00
63.00
5
2.50
10.00
14.50
5000
90
-
-
-
-
TGSF 80-3-22K
3.00
80.00
7
2.50
22.00
19.00
3900
90
-
-
-
-
TGSF 100-3-22K
3.00
100.00
8
2.50
22.00
29.00
4470
90
-
-
SW32-40
R 22-46
TGSF 125-3-32K
3.00
125.00
10
2.50
32.00
34.00
3820
90
-
-
S32-55
R 32-55
TGSF 160-3-32K
3.00
160.00
12
2.50
32.00
52.00
3000
90
-
-
S32-55
R 32-55
TGSF 63-4-10K
4.00
63.00
-
-
10.00
-
5000
90
-
-
-
-
TGSF 80-4-22K
4.00
80.00
-
-
22.00
-
3900
90
-
-
-
-
TGSF 100-4-22K
4.00
100.00
8
3.30
22.00
29.00
6000
90
-
-
SW32-40
R 22-46
TGSF 125-4-32K
4.00
125.00
10
3.30
32.00
34.00
3800
90
-
-
S32-55
R 32-55
TGSF 160-4-40K
4.00
160.00
12
3.30
40.00
39.00
3000
90
-
-
S40-80
R 40-80
ETG extractor should be ordered separately.
For drive flange set dimensions, refer to "Related Holder"
