FDN-CALN12 :
Full slot, adjustable slotting cutters with cartridges using tangentially clamped LNET 12 inserts, 6.0-10.5 mm width range. The narrow and accurate slitting capability is used for applications like slitting bearing caps.
Designation
D
Z
Zeff
Da
D3
Tmax
ap
min
ap
max
Hmin
Hmax
L
min
L
max
Kg
FDN D100-0608-27R-CALN12
100.00
6
3
27.00
55.00
26.00
6.00
8.20
28.4
29.5
40.0
41.1
0.49
FDN D100-0810-27R-CALN12
100.00
6
3
27.00
55.00
26.00
8.00
10.50
30.2
31.5
42.0
43.2
0.54
FDN D100-1014-27R-CALN12
100.00
6
3
27.00
55.00
26.00
10.50
14.60
32.0
34.0
44.5
46.5
0.61
FDN D125-0608-32R-CALN12
125.00
8
4
32.00
65.00
34.00
6.00
8.20
30.2
31.3
45.0
46.1
0.80
FDN D125-0810-32R-CALN12
125.00
8
4
32.00
65.00
34.00
8.00
10.50
32.0
33.3
47.0
48.2
1.36
FDN D125-1014-32R-CALN12
125.00
8
4
32.00
65.00
34.00
10.50
14.60
33.7
35.8
49.5
51.5
1.02
FDN D160-0608-40R-CALN12
160.00
12
6
40.00
80.00
44.00
6.00
8.20
29.6
30.7
45.0
46.1
1.29
FDN D160-0810-40R-CALN12
160.00
12
6
40.00
80.00
44.00
8.00
10.50
29.5
30.7
45.0
46.2
1.46
FDN D160-1014-40R-CALN12
160.00
12
6
40.00
80.00
44.00
10.50
14.60
31.2
33.2
47.5
49.5
2.16
FDN D200-0608-40R-CALN12
200.00
16
8
40.00
92.00
51.00
6.00
8.20
-
-
45.0
46.1
2.20
FDN D200-0810-40R-CALN12
200.00
16
8
40.00
92.00
51.00
8.00
10.50
-
-
45.0
46.2
2.20
FDN D200-1014-40R-CALN12
200.00
16
8
40.00
92.00
51.00
10.50
14.60
-
-
45.0
47.0
2.40
FDN D250-0608-60R-CALN12
250.00
20
10
60.00
132.00
56.00
6.00
8.20
-
-
48.0
49.1
5.32
FDN D250-0810-60R-CALN12
250.00
20
10
60.00
132.00
56.00
8.00
10.50
-
-
48.0
49.2
4.65
FDN D250-1014-60R-CALN12
250.00
20
10
60.00
132.00
56.00
10.50
14.60
-
-
48.0
50.0
6.23
For adaptation, click on "More Info".
For cartridges, click on "More Info".
