| Designation |
SS |
Tap
min |
Tap
max |
L1 |
L |
D1 |
d2 |
Flf |
Flb |
Kg |
|
TP MB50-M 3-12
|
MB50 |
M3 |
M12 |
60.0 |
72.00 |
36.0 |
19.00 |
7.5 |
7.5 |
0.78 |
|
TP MB50-M 8-20
|
MB50 |
M8 |
M20 |
- |
106.00 |
53.0 |
31.00 |
12.5 |
12.5 |
1.64 |
|
TP MB63-M 3-12
|
MB63 |
M3 |
M12 |
58.0 |
70.00 |
36.0 |
19.00 |
7.5 |
7.5 |
1.14 |
|
TP MB63-M 8-20
|
MB63 |
M8 |
M20 |
93.0 |
104.00 |
53.0 |
31.00 |
12.5 |
12.5 |
1.88 |
|
|
Verify that the weight of the entire tool assembly does not exceed the machine spindle's carrying capability.
|
 |
    |
